Marantz AV20/N1B

13.4-kanaals gebalanceerde AV-voorversterker van referentiekwaliteit Powered by HEOS™ De AV 20 biedt de allerbeste prestaties en mogelijkheden voor thuisbioscoopsystemen van topkwaliteit. Deze 13.4-kanaals gebalanceerde AV-voorversterker is voorzien van discrete Marantz HDAM-schakelingen, zeven 8K UHD-compatibele HDMI-ingangen, Dolby Atmos, DTS:X Pro, AURO-3D en vier onafhankelijke subwooferuitgangen voor geavanceerde thuisbioscoopinstallaties op maat. Geproduceerd in Shirakawa, Japan 13.4 Kanalen 7 HDMI-ingangen plus eARC 8K en Dolby Atmos 3D-audio HEOS Built-In Specifications: Multichannel Surround Technologies: DTS DTS-HD, DTS:X, DTS:X Pro, DTS Virtual:X, DTS Neural:X (13ch) Dolby Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround IMAX IMAX Enhanced Auro 3D / 360 Reality Audio / MPEG H Yes / Yes / Yes Multichannel Stereo Yes Max. Number of Processing (Pre-Amp) Channels 13.4 Sound Enhancements Copper-Plated Chassis / Toroidial Power Transformer Yes / Yes Current Feedback Topology / Hyper Dynamic Amplifi er Modules (HDAM) Yes / Yes (SA3, monolithic) Pure Direct / Gold-Plated RCA Terminals Yes / Yes Clock Jitter Reducer Yes Dirac Live Upgradability Yes Compressed Audio Enhancer: MDAX2 Yes Audyssey Dynamic EQ / Dynamic Volume / Audyssey LFC Yes / Yes / Yes Audyssey MultEQ XT32 Network: Wi-Fi / Bluetooth / Ethernet Yes / Yes / Yes HEOS Multi-Room and Streaming Yes Bluetooth Retransmit for Bluetooth Headphones Yes Apple HomePod Yes Lossy Formats MP3, WMA, AAC Lossless Formats FLAC, FLAC HD 192/24, ALAC, ALAC 192/24, WAV, WAV 192/24 DSD Audio Streaming Yes (2.8/5.6 MHz) Gapless Playback FLAC, ALAC, WAV, DSD TuneIn / AirPlay 2 / Spotify Yes / Yes / Yes Roon-Ready Yes Other Streaming Services Amazon Music / TIDAL / Deezer / Napster / Soundcloud Compatible with Remote App for Smartphones Marantz AVR Remote Compatible with Remote App for Tablets Android / iOS / Amazon Kindle HDMI: Total HDMI Inputs 7 (rear) HDCP 2.3 Support Yes HDMI Outputs: Main / Zone 2 / 1 HDMI Upscaling 1080p/4K to 8K GUI Overlay on HDMI Yes HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB Yes / Yes 8K/60Hz AB / 4K/120Hz AB Pass-Through In/Out 7 / 2 (up to 40 Gbps) HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR Yes / Yes / Yes / Yes / Yes Enhanced ARC Yes ALLM (Auto Low Latency Mode) Pass-Through for Gaming Yes Variable Refresh Rate / Quick Frame Transport Yes / Yes HDMI Pass-Though in Standby Mode Yes DSD Audio Capability Yes Auto LipSync Yes Inputs/Outputs: Video Composite In / Out 2 / 0 Component In / Out 1 / 0 HDMI In / Out 7 / 3 Multi-Room Video Out: Video / HDMI No / Yes Audio Analogue In 6 (1× XLR) Phono (MM) In Yes Digital In: Optical / Coaxial 2 / 2 Multi-Room Out: Analog / Digital 2 / 0 Multichannel Pre-Amp Out Yes (15.4 RCA, 15.4 XLR) Subwoofer Out 4 (independent) RCA, XLR Other Speaker A / B Assignable Pre-Out Bi-Amp Drive Assignable Pre-Out Front USB Input / USB Audio Yes / Yes USB Power Supply (Rear) Yes AM/FM Tuner Yes Multi-Room: HEOS Multi-Room Integrated Yes HEOS Link Compatibility: IR/ IP Yes / Yes Multi-Room Zones 3 Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analogue Yes (2 ch) / Yes (2 ch) / Yes / Yes Zone Audio Output: Speaker / Pre-Out No / Yes Zone HDMI Output from HDMI Source Yes IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes IR Flasher In / Marantz Remote Bus Yes / Yes DC Trigger Output 3 HDMI Diagnostics Yes Others: Auto Speaker Setup by Microphone Audyssey MultEQ XT32 Dirac Live (Upgrade) Front Display 2-Line FLD, Port Hole OLED Graphic User Interface Modern HD GUI GUI Languages 3 Setup Assistant / Smart Select Yes / Yes Firmware Update by Network / USB Yes / Yes Variable Cross Over / Optimized Bass Redirection / Bass Sync Yes / Yes / Yes Auto Power Off / Sleep Timer Yes / Yes General: Metal Front Panel Yes System Remote Control RC051SR Backlit Yes Power Consumption 90 W Standby Consumption 0.2 W CEC Standby Consumption 0.5 W Network Standby Consumption
